Laboratories

Mechatronics Engineering - Laboratories

Industrial Automation Laboratory

PLC (Siemens, Allen Bradley, Delta, Millennium)
Multi process Station
Stepper Motor, DC motor control using PLC
Digital Controller (I to V converter, V to I converter, ADC/DAC)
Variable Frequency Drive
Number of Computers : 12
Intel core i3, 2GB RAM, 500GB HDD
List of Available Softwares:
SIMANTIC STEP 7 V 15.1
Siemens LOGO SOFT V 8.0
Delta ISP Soft V3.07
WPL Soft simulation software
Connected component workbench 12.0
SCADA software-Open Source

Computer Aided Design and Computer Aided Manufacturing Laboratory

Number of Computers: 33
Number of Printer: 02
Number of Plotters: 01
Intel core i3 3.3 Ghz, 4GB RAM, 500GB SATA HDD
List of Available Softwares:
Autodesk products
CATIA V6
Solid Works
Master CAM

Fluid Power Systems Laboratory

FRANK 20HP Screw Compressor
Pneumatic Trainer Kit
Electro Pneumatic Trainer Kit
MAP station with Siemens PLC
Electro Hydraulic Assembly Kit
List of Available Softwares:
AutoSIM-200
Automation Studio V5.7

Robotics Laboratory

1 DOF robot
2 DOF robot
4 DOF robot
3D Printer
Number of Computers : 32
Intel core i3, 4GB RAM, 500GB HDD
List of Available Softwares:
ADAMS
Robotic Operating System
